[16th Feb 2023]

Introduce To dixit sir on the first day. There was a discussion about the project, then Dixit sir told some works about the previous project, society waste composters. Dixit sir asked whether the society waste composters project can be modified. A mixer was in working condition and asked to change its tumbler. And was asked to Modification of another mixer.

Then after talking to mahesh dada went to see the Composter mixer & collected information from him & sir said to see if something can be designed.

And After taking the measurement of that mixer ( Working condition ) And studying it, & analyzing, How can it be designed.

To taking a measurement

17 Feb 2023

The next day one of the two mixers that were out of order was brought to the workshop and dismantle & analyzed.

Total two mixers were out of order and one mixer was brought to the workshop and dismantled and analyzed and removed the Tumbler of the second out of order mixer and fitted it to the one that was in running condition and removed the old one and installed the new Tumbler.

18 Feb 2023

I had a discussion with Prasad sir and explained him about my plan and he asked me to do some work related to that

Problem .

The Next Day There was a discussion with Prasad sir about the project, but sir asked to do some work in relation to the project, first planning rough drawing and how it can be modified.

And Draw the three views & Analyzing That’s Project. ( Roughly Without Dimensions )

3 View of the project

Problem

Whatever mixed waste in Tumbler  was not falling properly

Solution

So when we first studied the tumbler and looked at what the problem was, we found that whatever the mixed Waste material was, it didn’t fall down because the space was shaped like a flat surface. A sheet was cut in a square shape on a flat surface but as much of the material fell into the square hall has the material feel, the rest remained on the side.

Then we decided to change its shape to create a rectangular funnel so that the mixed waste would fall properly.

I modeled it through Job Design Catia software

Conclusion

we designed it, But this tumbler has no use now, Since there is no use at present, the fabrication work has been stopped
