Introduction

Physical work at industry or farm is very laborious and exhausting, which may be leads to several muscle and bone health issue. Working on repetitive task for hours will leads to muscle pain, and if the work is continued for weeks and months and years the worker may face a muscles health related issue. Which makes natural movements restricted. Which are called as work-related musculoskeletal disorders (WMSDs).
So moto of the project is to reduce the human efforts while working in any sector with heavy and repetitive work.

Problem Statement

Reduce the fatigue and efforts required to do the repetitive and exhaustive task in farming industry.

Literature Review

Studied the ongoing research and technical advancements in the field of exoskeleton, although we all think IronMan is hypothetical but with advancing technologies we are ready to make one with limited capabilities. Here i am providing some of the links to refer.

HAL (Hybrid Assistive Limb) by cyberdyne.

Comau an Italian company done a very good work on exoskeleton without using external power source (i.e. electricity, fuel)

Although different exoskeleton are designed for specific reason, we are trying to implement one in the agricultural sector where verity of work is to do on daily basis. But we found a common point the stress points are there, while working in farm stress is continuously exerted on lower back. So First a fall our aim is to design supportive system for bicep, shoulder, lower back and then knees.

Concept

A spring loaded passive exoskeleton which will reduce the efforts from one muscle and hence reduce the fatigue on that muscle, basically we are distributing some of the stress over another muscle, And we try to link different modules of exoskeleton in such a way a part of stress will be directed on the base i.e. ground.

Visit to Comau

Visiting comau helps us to understand the concept we are thinking is actually working and we can move on the theory we have built.

Proof of Concept

Material selected for the prototype Version 0.1 was 12 mm acrylic because of ease of availability and less time expenditure.

Used readily available crank spring and some of the screws.

Mechanism tested by fixing it over forearm and bicep with the help of Velcro tape.
While testing it is found that mechanism is giving support to the bicep while lifting the load, but design of strap need to improved.

Model design.

Designing the first model for the forearm and bicep support system was completed, with consideration of the spring placement.

Model Version0.2

Search for available hand calipers or braces

Instead of manufacturing entire assembly the idea was to search for available braces and directly implement spring mechanism.
So contacted Orthosis Mr Deepak at shivajinagar so to take look at available mechanisms.

Discussion with orthopedic doctors about the idea.

Personally met Dr. Pote at shikrapur and Dr. Date at narhe.
Got some of the trickiest movements to be considered while going forward to work with exoskeleton. And found out the assumption of the stressed areas made was correct for Knees and lower back and in forearm bicep and shoulder in some specific areas.

First Working Prototype.

After completing first design we started to built first working prototype.
Stages involved in the making the prototype are listed below.

  1. Found the suitable spiral spring with little bit of calculation and little bit of intuition.
  2. Found the suitable material, had selected 3mm thick and 25 mm broad MS plate in the design by considering to lift around 5-7 KG of weight.
  3. Welded the Nut on the bicep plate, with slot of 1mm made at its center to fix the spring.
  4. Fixed the center of the spring in the groove, and connected the forearm plate with bicep plate.
  5. Again connected Bicep plate with spring at its extreme support with rivet joint.
  6. Used custom made cushions for supporting the arm, and pasted Velcro at required position for tightening or loosening strap purpose.

Testing the working and experience of the first prototype.

prototype overview.

This image show how the exoskeleton will look like when we wore it.
This image shows the hand lifted by the spring force without using any of the muscle.
This image show the the position where our muscles need to do work to keep arm at this position.
How it looks

Experience

Prototype posses following advantages.

  • It gives support when we want to lift something with the use of bicep muscles.
  • It moves with our hand so do not restrict the relative motion between forearm and bicep.
  • It do not introduce any lag in motion.

It have disadvantages too.

  • It do not permit relative motion between forearm and wrist.
  • sometimes strap at bicep get loosen so introducing inefficiency while lifting load.
  • forearm support sometimes hurts little bit.
  • 2 standard springs used to support only arm of aprox 800 gms.

Improvement Needed.

  • Need to modify the Hand supporting brace designs so they don’t hurt.
  • Need to calculate the load for specific work and calculate the dimensions of the spring accordingly.
  • Need to modify bicep supporting brace to reduce sliding over bicep.

Experiment

Now we need to setup Standard Operating Procedure.
Here in following images we can see what are the variables need to be constrained to get the proper and accurate results.

So here are the defined variables needs to be considered.

  • Position of the foot of the subject.
  • Position of the end point of the Bamboo Stick.
  • Gesture of the subject.
  • Subjects head position.

SOP for the experiment.

  • Constrain the foot position of the subject.
  • Constrain the End point of the bamboo stick.
  • Set standard position where maximum load will be carried by the bicep muscles.
  • Make subject to look towards fruit and once towards camera.
  • Note down the endurance limit of each subject individually in seconds.
  • Repeat the experiment with exoskeleton.
  • Note down the endurance limit of each subject individually in seconds.
  • Compare the results.
  • Conclude or repeat the experiment with reinvented variables.

Re-designing and printing of the parts.

Here while setting SOP we found some issues which needs to be resolved.

  • Design of the forearm and bicep support as the previous one was pinching.
  • Last image below shows the tolerance provided to easily rotate the forearm and will not pinch or scratch on the the skin anymore.
  • Now cushioning is need to be provided to ensure maximum usability.
  • Velcro needs to be used for strap for holding support at its place.

Spring redesign and assembly.

We have used two steel springs for supporting the forearm in one prototype, now we need to design a single spring which will give the same force. following actions has been performed to select the suitable spring.

  • Practical exertion of the force by the springs is measured and it id 800 grams .
  • Steps needed to follow to achieve the same force with one spring. (i.e. increase in thickness and breath of the spring to match the combined thickness and breath.
  • Simulation of the springs with calculated dimensions.
  • Assembly of the newly purchased spring with version 2 mechanism.

Limitations of the new spring.

  • Newly designed spring deform when the same amount of displacement is done, but providing the force twice as that of previous springs.
  • While iterating with the spring dimensions limitation of simulation are there as we did not get the accurate and desired results.
  • Contacted different supports for getting accurate analysis, but still issue is not resolved.

Next steps

  • Cushioning needs to be provided to the newly designed parts.
  • Setting the experiment with the version 1 prototype with redesigned parts.
  • Collecting the Experiment data.
  • Studying the ways to simulate and analyze the spring.
  • Finding support for simulation of single part and complete model.

Participation in Fabcare16 challenge. (9th Aug-14th Aug)

Fabcare16 challenge gave us opportunity to take our project to the next level. We already made a prototype for Forearm but now we need to shift on the next upcoming part that is shoulder joint.
Here we have our day to day Challenges we have completed/ milestone achieved.

Day 1: Empathies. 11/08/2021

On the very first day we have to generate empathy for our customers, so instead of going somewhere else we choose to inspect our workplace i.e Vigyan ashram.
We found multiple areas where the working person is facing fatigue due to repetitive work, at our campus we rarely need some person to do the repetitive work, but similar kind of works are happening in the farming sector, and industrial sector the workers need to do same repetitive task for 6-8 hours a day and for at least a week for farming sector or may be multiple years in the industry.

Day 2: Ideation 12/08/2021

We had gone through different designs which can be implemented for the support system mentioned below.

Spiral spring based system.
This system uses spiral spring to store the potential energy due to weight of hand into spring as it gets wind and unwinding the spring will give the supportive force to the arm.

Pneumatic Cylinder based system.
We all knows air is compressible and so it can store the energy, this principle used in the air suspension for the heavy vehicle but here moto of compressing air is storing the energy instead of providing suspension to the system.

The Compression spring will be working on the same principle as that of the pneumatic cylinder but with less friction and so the design will be the same.

Day 3 : Prototyping and fabrication 13/08/2021

After the brainstorming with the team and checking the availability of the material we decided to work on Spiral spring based design as the system was easy to built and the required parts are readily available.

Our team worked so hard to get the prototype ready.
We used 12 mm metallic rod 2 no with approx. 30 cm length, a spiral spring with 1 mm thickness 10 mm of width, internal diameter 6 cm outer diameter 12 cm and number of turns were 6 in unstressed condition. in stressed condition our number of turns was 9.

Day 5: Presentation 14/08/2021

Great, till now we were focused an developing a solution and this were the most challenging and engaging days.
We did it all right now the focus was presenting the solution.
I am inserting here a presentation which we presented.

Untitled

Announcement of winner at 3hr.41min.53sec

Returning back on the Forearm POC 16/08/2021

After Completing the challenge Now i am back on the forearm exoskeleton so our current design delivers about 800 gm of assistive force, but our target was around 2.5 kg so we implemented stronger spring then the previous. Currently it is giving the assistive force of 2000 gm or say 2 kg.

Designing the Spring holder box for the readymade hand caliper. 24/08/2021

Caliper Available in market.
